PARTS CATALOG

HK0003113

S-39011

BEARING, HN INNER BEARING ASSY ZWZ KIT, INNER CUP AND CONE ASSEMBLY

HK0001687

VS-32056-3

HUB CAP,HP GREASE DUAL TMX PRO HUBCAP, HXL5, .OUTSIDE DIAMETER 7-1/2" .INSIDE DIAMETER 5-1/2" .HEIGHT 3-7/16" .BOLTS 6 BOLT CIRCLE 6-3/4" .FLANGE OUTSIDE DIAMETER 7-1/2" .FLANGE INSIDE DIAMETER 5-1/2" .OVERALL HEIGHT 3-7/16"

HK0002976

S-35322-4

CAMSHAFT REPAIR KIT, CAM TUBE KIT 10 23.75

HK0003425

S-26105-1L

HK0003238

S-39887-2

HUBS, WHEEL HUB, TRAILER,DISC BRAKE TYPE, 10 STUD, STUD: M22 X 1.5 MM X 2-9/16 IN, BENDIX ADB22X-LT, WABCO PAN22 APPLICATION TYPE :- STEEL WHEELS MATERIAL ALUMINUM AXLE TN TRAILER -TAPERED SPINDLE ASSEMBLY TYPE PRESET HUB & ROTOR ASSEMBLY BEARING SET (INBOARD) :-SET: 414 OR 431 BEARING SET (OUTBOARD):-SET: 413 OR 427 COMPATIBLE BRAKE TYPE DISC ROTOR TYPE FLAT REPLACEMENT ROTOR KIT 10085621 HUB MOUNTING SYSTEM HP10 WHEEL STUD STANDOUT (IN.) 2.56 FLANGE OFFSET (IN.) 0.80 ABS TONE RING INCLUDED YES

HK0001013

VS-32056-1

HUB CAP, KIT PRO HP OIL HENDRICKSON, TIREMAAX TYPE HUB CAP KIT WITH HARDWARE FOR TIREMAAX PRO SERIES INFLATION SYSTEMS .MOUNTING HOLE COUNT:-6 .OVERALL DEPTH:-3.00 IN .FLANGE INNER DIAMETER:-5.00 IN .BOLT CIRCLE DIAMETER (BOLT ON):-6.00 IN .FLANGE OUTER DIAMETER:- 7.00 IN

HK0003116

S-39010

BEARING, HENDRICKSON S-39010 HP BEARING ASSEMBLY, ZWZ KIT

HK0002826

VS-30002

SUPER SINGLE ELBOW W/CHECK KIT, HENDRICKSON

HK0002800

VS-29566-3

HUBCAP, TIREMAAX HUB CAP PARTS KIT, TIREMAAX TYPE HUB CAP KIT WITH HARDWARE FOR TIREMAAX EC AND CP SERIES INFLATION SYSTEMS HN AXLE OIL

HK0003656

VS-41701-1

TIREMAXX HUB CAP, TIRE HOSE 110 DEG 10.3IN

HK0002865

S-28500-1650

DUST SHIELD,HENDRICKSON FOR 5.0IN ROUND AXLE WITH 16-1/2IN BRAKES HEIGHT: 2.0IN STEEL

HK0003290

S-37435-2

ROTOR KIT,AIR DISC BRAKE ,WABCO PAN22, 430MM HP ROTOR KIT

HK0002403

VS-33767-1

TIREMAXX HOSE, STRAIGHT, 15.5IN, DUAL PRO AND CP INTEGRATED"

HK0001753

ABH38000

AIR BAG - AIR SPRING ROLLING LOBE (TRAILER)

HK0001018

VS-32055-3

HUB CAP, PRO HN GREASE, HENDRICKSON, DUAL-SUPER SINGLE FLANGE INNER DIAMETER 4.00 IN, FLANGE OUTER DIAMETER 6.00 IN, OVERALL DEPTH 3.00 IN MOUNTING HOLE COUNT:- 6 BOLT CIRCLE DIAMETER (BOLT ON) 5.00 IN

HK0003762

S-24960

AXLE\FILTER KIT(HP AXLE), TIRE INFLATION SYSTEM FILTER KIT

HK0003094

S-37610-500

PARTS SELF-STEER DUSTSHIELD

HK0003686

S-28192

ROTARY UNION SPINDLE PLUG RETROFIT, TIREMAAX HN

HK0003428

ULTRAA-K HANGER LF-RR-O

HANGER, TRAILER, OUTER PLATE, HENDRICSON ULTRAA-K SUSPENSION, LEFT FRONT OR RIGHT REAR

HK0003155

105760

HUBS, WHEEL HUB, TRAILER, DRUM BRAKE AND HUB ASSEMBLY - 9 IN. DRUM, TAPERED SPINDLE, ALUMINUM, 3.80 IN. STUD, WITH ABS TONE RING MOUNTING HUB PILOTED - 8 STUDS ABS YES WHEEL STUD BOLT CIRCLE DIAMETER 275 MM WHEEL STUD 102190 WHEEL STUD STANDOUT 3.80" HUB CAP BOLT CIRCLE DIAMETER 5.500" DRUM PILOT DIAMETER 9.00" CUP, BEARING - OUTBOARD 100015 CUP, BEARING - INBOARD. 100014 CAN USE FOR BOTH STEEL AND ALUMINUM WHEELS ALTERNATIVE FOR 105769

HK0002867

S-28146-3

SPINDLE PLUG DRIVER TIREMAAX HP/HUS, 2.75IN DIAMETER HP AND HUS AXLES

HK0004540

S-34886

MUDFLAP HANGER KIT HENDRICKSON, HENDRICKSON ULTRAA-K UTKNT 40K SLIDER BOX FITS ON BOTH LEFT ANF RIGHT SIDE, BLACK

HK0003529

S-33061-1R

FRAME BRACKET ASSEMBLY, BOLT ON FRAME BRACKET, STANDRED TRAVEL AND SHOCK MOUNT

HK0000976

VS-227

HEIGHT CONTROL VALVE,HENDRICKSON, HCV NON-DELAY, 3-PORT 130 MAX PSI FOR INTRAAX, INTRAAX SP, CONNEX, VANTRAAX ADJUST ARM, 5.00IN AND 6.88IN AND 7.38IN
