PARTS CATALOG

HK0003725

AV110171

SPRING / BRAKE CONTROL VALVE, 90 DEGREE COVER PLATE, DEL: 3/8" (x4); SUP: 3/8"; CON: 3/8"; RES-A: 1/2"; RES-B: 3/8" ,

HK0003594

441-850005416

SHOCK ABSORBER, COLLAPSED LENGTH :-11.5, LENGTHS STROKE :-5.78, EXTENDED LENGTH:- 17.28,

HK0002974

S-31110-16L

S-CAM / CAMSHAFTS CAMSHAFT LH, - 12.25 HENDRICKSON HXS

HK0003138

373-0143

WHEEL SEAL, WHEEL SEAL/HUB SEAL DRIVE AXLE WHEEL OIL SEAL - 6" BORE, 4.625" SHOULDER OD, 0.981" WIDTH, L1 HUB CAP WITH GASKET 340-4013 INNER BEARING CONE HM218248 INNER BEARING CUP HM218210 SHOULDER OUTER DIAMETER 4 .625 IN BORE DIAMETER 6 IN. WIDTH 0.981 IN.

HK0003098

S-28570-4350

DUST SHIELD,HENDRICKSON, WABCO PAN22, BENDIX ADB22X-LT, HALDEX DB22LT PAN22 DISC BRAKE WITH 5.0IN DIA. AXLE

HK0003073

S-36837-9

CALIPER & THEIR REPAIR KITS AIR DISC BRAKE CALIPER PRESSURE PLATE AIR DISC - PRESSURE PLATE KIT WEB PAN17

HK0003322

S-33389-1

ROTOR, AIR DISC BRAKE, WEB PAN19 HENDRICKSON, DISCARD THICKNESS 37.0 MM MOUNTING BOLT HOLE CIRCLE DIAMETER 249.5 MM MOUNTING BOLT HOLE DIAMETER M16-2.0 MOUNTING BOLT HOLE QUANTITY 10.0 NOMINAL THICKNESS 45.0 MM OUTSIDE DIAMETER 375.0 MM OVERALL HEIGHT 150.1 MM ROTOR TYPE U-SHAPED

HK0003288

10016195

ROTOR, AIR DISC, FLAT,AIR DISC ROTOR 16.900IN BRAKE TYPE WABCO PAN22 ROTOR TYPE FLAT AOVERALL LENGTH 2.09 INCH BBRAKE SURFACE OUTSIDE DIAMETER Ø16.93 INCH CTHICKNESS 1.77 INCH DPILOT DIAMETER Ø 6.55 INCH E BOLT CIRCLE Ø7.86 INCH NUMBER OF BOLT HOLES 10

HK0002580

924-5822

AIR TANK, VOLVO VN, VHD, WET TANK, METRIC PORTS APPLICATIONS VOLVO TRAILER / TRUCK TRUCK DIAMETER (IN) 10.000" MAKE VOLVO CHAMBERS DUAL LENGTH 29.500" TANK MATERIAL STEEL BRACKETS TOP SIDE PORTS (1) M22X1.5 END PORTS (A) (1) M16X1.5, (1) 1/4" NPT TANK END PORTS (B) (3) M22X1.5, (2) M16X1.5, (1) 1/4" NPT

HK0002971

S-31110-34R

S-CAM / CAMSHAFTS CAMSHAFT RH,- 12.25 HENDRICKSON HXS

HK0003281

S-38764

ROTOR, AIR DISC BRAKE, WABCO PAN22, U-SHAPED ROTOR,430X45, 10 BOLTS, CENTER HOLE DIAMETER 220.0 MM

HK0002968

S-31110-34L

CAMSHAFT LH, 12.25 HENDRICKSON HXS

HK0003273

S-33386-6

HUBS, WHEEL HUB, TRAILER AIR DISC BRAKE, TAPPER SPINDLE TYPE,10 STUD X 11.25" , APPLICATION TYPE:- BOTH STEEL AND ALUMINUM WHEELS HENDRICKSON MAXX22T, WABCO PAN19, PAN22, HALDEX DB22LT HUBCAP HOLES 5/16-18 IN HUBCAP MOUNT (6) ON 5.50 IN INNER BREAING HM218248 INNER RACE HM218210 INNER SET SET414 OE REF NUMBER S-33386-2 OUTER BEARING HM212049 OUTER RACE HM212011 OUTER SET SET413 OVERALL HEIGHT 7.22 IN WEIGHT 56.900000 WHEEL MOUNT (10) ON 11.25 IN WHEEL OFFSET .79 IN WHEEL SEAL WS880025 WHEEL STUD 13-1572

HK0003106

S-32844/2

SPINDLE NUT/AXLE NUT KIT HENDRICKSON PRECISION 320

HK0002416

S-2212

SHOCK ABSORBER , HENDRICKSON, INTRAAX AAL 23K/25K/ 30K, COLLAPSED LENGTH :- 13.11, LENGTHS STROKE:- 7.43, CONTROLS REBOUND:- 1019, CONTROLS COMPRESSION:- 219, EXTENDED LENGTH:- 20.54,

HK0002961

S-30594-8R

CAMSHAFT RH,HEAD THICKNESS 1.13 IN,SPLINE QUANTIT 28, UNDER S-HEAD TO SNAP RING LENGTH 17.38 IN

HK0003074

S-36838-9

CALIPER & THEIR REPAIR KITS AIR DISC BRAKE CALIPER PRESSURE PLATE AIR DISC - PRESSURE PLATE KIT WEB PAN19

HK0003282

S-35210-3

ROTOR NUT AND BOLT ASSEMBLY,WABCO PAN22, PAN19, BOLT KIT ADR500/703/706

HK0003084

S-22889-1

ABS SENSOR, WHEEL SPEED SENSOR - 19.7 INCH, STRAIGHT

HK0003079

S-29152-9

CALIPER & THEIR REPAIR KITS AIR DISC BRAKE ,DISC BRAKE CALIPER PIN KIT AIR DISC - GUIDE PIN KIT ADB22X

HK0004395

12-27200E

AIR HOSE ZINC POGO STICK - 40 IN

HK0003101

S-36224-4430

DUST SHIELD,SERVICE KIT 430, WABCO PAN22, BENDIXADB22X-LT

HK0003266

S-36700-2

HUBS, WHEEL HUB, TRAILER, PARALLEL SPINDLE, AIR DISC BRAKE, 10 STUD X 11.25" BC WABCO PAN22, APPLICATION TYPE :- BOTH STEEL AND ALUMINUM WHEELS HUB MATERIAL :- DUCTILE IRON, DRUM/ROTOR PILOT 8.66 IN HUBCAP HOLES 5/16-18 IN HUBCAP MOUNT (6) ON 6.75 IN OUTER AND INNER BEARING HM518445 OUTER AND INNER RACE HM518410 OUTER AND INNER SET SET415 OVERALL HEIGHT 8.09 IN WEIGHT 58.200000 WHEEL MOUNT (10) ON 11.25 IN WHEEL OFFSET 1.79 IN WHEEL SEAL WS880065 WHEEL STUD 13-1572

HK0003261

S-41683-2

HUBS, WHEEL HUB, TRAILER , AIR DISC BRAKE, 10 STUD X 11.25" BC, TAPPER SPINDLE APPLICATION TYPE :- BOTH STEEL AND ALUMINUM WHEELS MATERIAL TYPE :- DURA LIGHT HUB IT CAN BE SUBSTITUTE FOR S-41683-1, S-41683-3, S-41683-4
