PARTS CATALOG

HK0003102

S-36832-1

DUST SHIELD, 5 TRLAXLE 325 ROTOR, WABCO PAN17

HK0003097

S-35720-1

HK0003322

S-33389-1

ROTOR, AIR DISC BRAKE, WEB PAN19 HENDRICKSON, DISCARD THICKNESS 37.0 MM MOUNTING BOLT HOLE CIRCLE DIAMETER 249.5 MM MOUNTING BOLT HOLE DIAMETER M16-2.0 MOUNTING BOLT HOLE QUANTITY 10.0 NOMINAL THICKNESS 45.0 MM OUTSIDE DIAMETER 375.0 MM OVERALL HEIGHT 150.1 MM ROTOR TYPE U-SHAPED

HK0003217

S-36163-1

HUBS, WHEEL HUB, TRAILER, PARALLEL SPINDLE, DRUM BRAKES, 8 STUD X 275MM BC, APPLICATION:- STEEL WHEELS BRAKE SIZE:- 12.25 X 7.5" STANDRED SERVICE :- HXL5

HK0003814

S-36566-1R

FRAME BRACKET LH HENDRICKSON, CURBSIDE, FOR CURBSIDE USE S-36566-1R INTRAAX AAT 23K/25K/30K, 13.5IN 14.0IN AND 15.0IN RIDE HEIGHT, 8.0IN WINGED BOLT ON 1/2IN BOLT SIZE, TOP TO ALIGN HOLE: 8"

HK0003764

S-36186-11

SURELOK, RIDE HEIGHT LOCK ASSEMBLY, FOR VANTRAAX HKANT 23K/40K/46K/69K23 AND HKA180, HKAT 46K

HK0003791

S-36562-1L

FRAME BRACKET WELDMENT, BOLT ON, FOR 13.5" , 14", 15" RIDE HEIGHT SUSPENSION

HK0003792

S-36562-1R

FRAME BRACKET WELDMENT, BOLT ON, RIGHT SIDE, FOR 13.5" , 14", 15" RIDE HEIGHT SUSPENSION

HK0002721

S-38100-1

SUSPENSION - BUMP STOP MOUNTING KIT DOWN STOP KIT

HK0003168

S-38163-1

HUBS, WHEEL HUB, HENDRICKSON HUB ASSEMBLY WHEEL MATERIAL STEEL TAPPER SPINDLE TRAILER HUB, 12.25" BRAKE, HM518410 INNER CUP, HM518410 OUTER CUP BRAND: APPLICATION:- HLS, HVS,HXL3, HXL5 HENDRICKSON SHORT DESCRIPTION: WIDTH: 12.001 LENGTH: 12.001 WEIGHT: 46.3

HK0003394

S-35295-1

LINE ACTUATOR , REAR , HENDRICKSON TYPE, 42" BOX, COMES WITH STRAIGHT FITTING, MAX INFLATION TO 120 PSI COMPOSITE TYPE BUILT AFTER 02-2015, (WITH U FITTING AT TAIL FOR COUPLING)

HK0003074

S-36838-9

CALIPER & THEIR REPAIR KITS AIR DISC BRAKE CALIPER PRESSURE PLATE AIR DISC - PRESSURE PLATE KIT WEB PAN19

HK0003239

S-39887-1

HUBS, WHEEL HUB, TRAILER, DISC BRAKE TYPE, 10 STUDS, PRESET, BENDIX ADB22X-LT, WABCO PAN22 APPLICATION TYPE :- BOTH ALUMINUM AND STEEL WHEELS, LONG STUD MATERIAL ALUMINUM AXLE POSITION TRAILER AXLE TN TRAILER -TAPERED SPINDLE ASSEMBLY TYPE PRESET HUB & ROTOR ASSEMBLY BEARING SET (INBOARD):-SET: 414 OR 431 BEARING SET (OUTBOARD):-SET: 413 OR 427 COMPATIBLE BRAKE TYPE DISC ROTOR TYPE FLAT REPLACEMENT ROTOR KIT 10085621 HUB MOUNTING SYSTEM HP10 WHEEL STUD STANDOUT (IN.) 3.44 WHEEL MATERIAL ALUMINUM WHEELS FLANGE OFFSET (IN.) 0.80 ABS TONE RING INCLUDED YES WEIGHT (LBS.) 126 PRESET / PRESET PLUS HUB REBUILD KIT

HK0003262

S-39888-1

HUBS, WHEEL HUB, TRAILER ,AIR DISC BRAKE , PARALLET SPINDLE, 10 STUD X 11.25" BC, BENDIX ADB22X-LT, WABCO PAN22 AIR DISC BRAKE APPLICATION TYPE:- BOTH STEEL AND ALUMINUM WHEELS HUB MATERIAL :_ ALUMINUM IT CAN BE SUBSTITUTE FOR S-39888-2 OR 10082491

HK0003251

S-34576-1

HUBS, DrWHEEL HUB, TRAILER, TAPPER SPINDLE, AIR DISC BRAKE , 10 STUD, WABCO PAN22, HALDEX DB22LT APPLICATION TYPE :-STEEL WHEELS ( SHORT STUD) ABS NO BETWEEN THE RACES 3.34 IN DRUM/ROTOR BOLT CIRCLE (10) ON 9.82 IN UM/ROTOR PILOT 8.66 IN HUBCAP HOLES 5/16-18 IN HUBCAP MOUNT (6) ON 5.50 IN INNER BREAING HM218248 INNER RACE HM218210 INNER SET SET414 OUTER BEARING HM212049 OUTER RACE HM212011 OUTER SET SET413 OVERALL HEIGHT 7.22 IN WHEEL SEAL WS880025 WHEEL STUD 13-1571

HK0003389

S-35294-1

FRONT LINER ACTUATOR KIT, HENDRICKSON STYLE, COMPOSITE BUILD, COMMON IN UNITS BUILD IN FEB 2015 AND AFTER, MAX INFLATION TO 120 PSI,

HK0003813

S-36566-1L

FRAME BRACKET LH HENDRICKSON, ROADSIDE, FOR CURBSIDE USE S-36566-1L INTRAAX AAT 23K/25K/30K, 13.5IN 14.0IN AND 15.0IN RIDE HEIGHT, 8.0IN WINGED BOLT ON 1/2IN BOLT SIZE, TOP TO ALIGN HOLE: 8"

HK0002868

S-34821-1

SUSPENSION - BUMP STOP MOUNTING KIT

HK0003472

S-35761-1

SUSPENSION - BUMP STOP MOUNTING KIT, END STOP; BOLT ON, LEFT FRONT/ RIGHT REAR

HK0003289

S-37435-1

ROTOR, AIR DISC BRAKE, KIT,430MM HN ROTOR KIT

HK0003100

S-36224-1

DUST SHIELD,430 BOLT-ON DUST SHIELD, WABCO PAN22, BENDIX DB22X-LT

HK0003061

S-33649-1

CALIPER & THEIR REPAIR KITS DISC BRAKE CALIPER HARDWARE KIT AIR DISC - AXIAL MOUNT BOLT KIT ADB22X

HK0003103

S-36832-4325

DUST SHIELD, KIT 5 TRLAXLE 325 RT, WABCO PAN17

HK0003165

S-35216-1

HUBS, WHEEL HUB,HUB ASSY HN DRUM 11.25 BC SS, 10 STUD TAPPER SPINDLE 15" *8-5/8", 16.5" * 7" , 16.5" * 8-5/8" WHEEL MATERIAL STEEL STANDRED SERVICE:- HLS,HVS,HXL7
