PARTS CATALOG

HK0003261

S-41683-2

HUBS, WHEEL HUB, TRAILER , AIR DISC BRAKE, 10 STUD X 11.25" BC, TAPPER SPINDLE APPLICATION TYPE :- BOTH STEEL AND ALUMINUM WHEELS MATERIAL TYPE :- DURA LIGHT HUB IT CAN BE SUBSTITUTE FOR S-41683-1, S-41683-3, S-41683-4

HK0003949

S-21688-1

WINGLESS WELD-ON FRAME BRACKET, QUIK-ALIGN, ROADSIDE, FOR HT HT250U

HK0003323

S-41533-1

ROTOR, AIR DISC, HENDRICKSON MAXX22T TYPE, 415MM MOUNTING BOLT HOLE CIRCLE DIAMETER 285.8 MM (SHORT STUD HUB) MOUNTING BOLT HOLE DIAMETER 0.98 IN MOUNTING BOLT HOLE QUANTITY 10.0 NOMINAL THICKNESS 43.0 MM USE WITH S370242 LONG STUDS FOR S-41533-2 OUTSIDE DIAMETER 415.0 MM OVERALL HEIGHT 169.3 MM PACKAGE CONTENTS 1 ROTOR, 10 WHEEL STUDS - SHORT ROTOR TYPE U-SHAPED

HK0003102

S-36832-1

DUST SHIELD, 5 TRLAXLE 325 ROTOR, WABCO PAN17

HK0003971

S-24183-1

FRAME BRACKET ASSEMBLY, ROAD SIDE, WELD ON ,HT300U MODEL, BB9-022

HK0003805

S-21083-1

HANGER LH HENDRICKSON/TURNER, AA230, AA250, AAT 23K, 25K, 30K QUICK-ALIGN, WINGED, WELD-ON, STANDARD TOP PLATE RIDE HEIGHTS: 18.0IN, 19.0IN, PIVOT HEIGHT: 12.0IN ROADSIDE, FOR CURBSIDE USE S-21083-1

HK0003327

S-41663-2

ROTOR REPAIR KIT, OMR ROTOR REPLACEMENT KIT, MAXX22T CONTAIN 1 ROTOR/FLANGE, 12 FLANGE NUTS, 6 CALIPER BOLTS, 6 CALIPER WASHERS
