AB1DK23I-8803

AIR BAG-AIR SPRING ROLLING LOBE • 5-5/8 INCH PISTON HGT. • PLASTIC BASE APPLICATIONS RIDEWELL SAF HOLLAND/NEWAY TYPE ROLLING LOBE AIRSPRING BRAND AUTOMANN PHOENIX AUTOMANN BELLOWS # 1DK23I FIRESTONE BELLOWS# 1T15M-4 CONTITECH BELLOWS# 9 10-13.5 LOAD (LBS) @80 PSI 5600 LOAD (LBS) @100 PSI 7100 NATURAL FREQ. (CPM) 74 DESIGN HEIGHT (IN) 11.50 BOTTOM PLATE TYPE PLASTIC TOP PLATE HOLE/STUD QTY 2 TOP PLATE DIA. (A) 9.00 TOP PLATE C TO C DIA. (B) 5.50 BOTTOM PLATE HOLE/STUD QTY 1 BOTTOM PLATE DIA. (C) 10.28 BOTTOM PLATE C TO C DIA. (D) N/A BOTTOM PART # BS14552 BUMPER YES BRACKET N/A MIN. HEIGHT 7.30
